Oil Pump And Controls


Schematic: Oil Pump And Controls
Schematic: Oil Pump And Controls
Loc
Part
Cond       Price
1
Stud Main Bearing [M10x114mm]
New       £ 15.97
CC10016n (1) Full qty
CC10016n
1
Stud Main Bearing [M10x102mm]
New       £ 15.68
CC10018n (1) Full qty
CC10018n
1
Stud Main Bearing (M8x108mm)
New       £ 15.68
P2 (1) Full qty
CC10019n
1
Stud Main Bearing [M10x127mm]
New       £ 16.89
CC10020n (1) Full qty
CC10020n
1
Stud Main Bearing [M10x94mm]
New       £ 7.87
P2 (1) Full qty
CC10021n
1
Stud Main Bearing (M10x121mm)
New       £ 16.89
P2 (1) Full qty
CC10025n
1
Stud Main Bearing (M10x120mm)
New       £ 15.35
P2 (1) Full qty
CC10026n
1
Stud Main Bearing (M10x94mm) 48mm Shank
New       £ 15.31
P2 (1) Full qty
CC10027n
1
Stud Inlet Manifold
New       £ 9.99
CH11508n (1) Full qty
CH11508n
1
Water Manifold Stud
New       £ 8.42
CS11797n (1) Full qty
CS11797n
1
Carburettor Mounting Stud
FU14217n (1) Full qty
2
Stud Main Bearing [M10x114mm]
New       £ 15.97
CC10016n (1) Full qty
CC10016n
2
Stud Main Bearing [M10x102mm]
New       £ 15.68
CC10018n (1) Full qty
CC10018n
2
Stud Main Bearing (M8x108mm)
New       £ 15.68
P2 (1) Full qty
CC10019n
2
Stud Main Bearing [M10x127mm]
New       £ 16.89
CC10020n (1) Full qty
CC10020n
2
Stud Main Bearing [M10x94mm]
New       £ 7.87
P2 (1) Full qty
CC10021n
2
Stud Main Bearing (M10x121mm)
New       £ 16.89
P2 (1) Full qty
CC10025n
2
Stud Main Bearing (M10x120mm)
New       £ 15.35
P2 (1) Full qty
CC10026n
2
Stud Main Bearing (M10x94mm) 48mm Shank
New       £ 15.31
P2 (1) Full qty
CC10027n
2
Stud Inlet Manifold
New       £ 9.99
CH11508n (1) Full qty
CH11508n
2
Water Manifold Stud
New       £ 8.42
CS11797n (1) Full qty
CS11797n
2
Carburettor Mounting Stud
FU14217n (1) Full qty
3
Stud Main Bearing [M10x114mm]
New       £ 15.97
CC10016n (2) Full qty
CC10016n
3
Stud Main Bearing [M10x102mm]
New       £ 15.68
CC10018n (2) Full qty
CC10018n
3
Stud Main Bearing (M8x108mm)
New       £ 15.68
P2 (2) Full qty
CC10019n
3
Stud Main Bearing [M10x127mm]
New       £ 16.89
CC10020n (2) Full qty
CC10020n
3
Stud Main Bearing [M10x94mm]
New       £ 7.87
P2 (2) Full qty
CC10021n
3
Stud Main Bearing (M10x121mm)
New       £ 16.89
P2 (2) Full qty
CC10025n
3
Stud Main Bearing (M10x120mm)
New       £ 15.35
P2 (2) Full qty
CC10026n
3
Stud Main Bearing (M10x94mm) 48mm Shank
New       £ 15.31
P2 (2) Full qty
CC10027n
3
Stud Inlet Manifold
New       £ 9.99
CH11508n (2) Full qty
CH11508n
3
Water Manifold Stud
New       £ 8.42
CS11797n (2) Full qty
CS11797n
3
Carburettor Mounting Stud
FU14217n (2) Full qty
4
Carb Mounting Washer M8
8R5 (4) Full qty
4
Carburettor Base Nut M8x1 [11m…
8R5 (4) Full qty
4
Carb Mounting Washer M8
8R5 (4) Full qty
5
DADI
8D2 (4) Full qty
6
REAR BEARING HOUSING
520685 (1) Full qty
7
Oil Pump Housing 275 GTB/GTS 330 GTC Coup
New       £ 149.04
520649 (1) Full qty
SU11709n
8
THREADED STUD
P1 (1) Full qty
8
Stud (M6x24) Angle Drive/Water Pump
New       £ 3.58
CH11551n (1) Full qty
CH11551n
9
THREADED STUD
P1 (1) Full qty
9
Stud (M6x24) Angle Drive/Water Pump
New       £ 3.58
CH11551n (1) Full qty
CH11551n
10
WASHER
6R5 (2) Full qty
11
NUT
6D3 (2) Full qty
12
Transaxle Oil Pump Bush 275
New       £ 51.82
520675 (4) Full qty
AX22429n
13
DRIVEN GEAR
520674 (1) Full qty
14
DRIVING GEAR
520673 (1) Full qty
15
PLUG
TF4 (2) Full qty
16
Oil Pump Cover 275 GTB/GTS 330 GTC Coup
New       £ 138.04
520650 (1) Full qty
SU11711n
17
SCREW
5X12 (3) Full qty
18
Reverse Light Switch M10x1.0
New       £ 48.35
95403254 (1) Full qty
GB10156n
18
Reverse Light Switch M10x1.0
New       £ 48.35
95403254 (1) Full qty
GB10156n
18
Reverse Light Switch M12x1.5
New       £ 48.35
95403254 (1) Full qty
GB10554n
18
Reverse Light Switch M12x1.5
New       £ 48.35
95403254 (1) Full qty
GB10554n
19
WASHER
RO024 (1) Full qty
20
Rev Light Switch Plunger 365 GTB/4 Daytona
New       £ 71.39
55670 (1) Full qty
GB10401n
21
Selector Shaft 1+12 275 GTS/GTB 330 GTC
New       £ 116.04
520682 (1) Full qty
GB10353n
22
SELECTOR FORK 1ST REVERSE. 4TH…
520149 (2) Full qty
23
Lock Tab
New       Price on Enquiry
103587 (4) Full qty
GB10280n
24
BOLT
B9 (3) Full qty
25
SELECTOR FORK 2ND AND 3RD VEL.…
520150 (1) Full qty
26
M8 lockwire bolt 250
New       Price on Enquiry
93231 (2) Full qty
GB00250n
26
Selector Bolt
New       £ 16.45
93231 (2) Full qty
GB10544n
27
Selector Fork 4th&5th 275
New       £ 646.25
520680 (1) Full qty
GB10079n
27
Selector Fork 4th/5th
New       Price on Enquiry
520680 (1) Full qty
GB10506n
28
Selector Shaft 2+3 275 GTB/GTS 330 GTC
New       £ 120.45
520683 (1) Full qty
GB10351n
29
Selector Fork 1st & Reverse (275)
New       £ 463.99
520679 (1) Full qty
GB10147n
29
Selector Fork 1st/Rv
New       Price on Enquiry
520679 (1) Full qty
GB10504n
30
CENTERING DOWEL
BF1 (3) Full qty
31
SHIFT CONTROL BOX
520542 (1) Full qty
32
FERRULE
520565 (1) Full qty
33
SPRING
520567 (1) Full qty
34
BOTTOM
520569 (1) Full qty
35
SEEGER RING
AA201 (1) Full qty
36
RULLINO ASTA 2ND 3RD E VEL.
53126 (1) Full qty
37
RULLINO ASTE 1ST R.M. - 4TH E …
520146 (2) Full qty
38
PIVOT JOINT
520544 (1) Full qty
39
Gear Linkage U Joint
New       £ 175.95
103189 (2) Full qty
GB10486n
40
NUT
12D4 (1) Full qty
41
TIE ROD
521362 (1) Full qty
42
NUT
520465 (1) Full qty
43
SYMBICORT BAR COMMAND
521339 (1) Full qty
44
PIN
93370 (3) Full qty
45
Transaxle Side Plate 330 GTC / 365 GTB/4 Daytona
New       Price on Enquiry
521212 (1) Full qty
GB10531n
45
Transaxle Side Plate 330 GTC / 365 GTB/4 Daytona
Used       £ 874.50
521212 (1) Full qty
GB10531u
46
Selector Fork 2nd/3rd 275
New       £ 724.79
520148 (1) Full qty
GB10080n
47
Gearbox Front Gasket 275
520648 (1) Full qty
47
Gearbox Seal Kit 275
520648 (1) Full qty
48
Gearbox Side Plate Gasket 275
520651 (1) Full qty
49
Selector Shaft 365 GTB/4 Daytona
New       £ 1566.95
520183 (1) Full qty
GB10395n
50
Selector Fork 365 GTB/4 Daytona
New       £ 97.96
520166 (1) Full qty
GB10397n
51
GEAR KNOB
520396L (1) Full qty
51
Gear Knob 250/Lusso Long
New       £ 237.02
520396 (1) Full qty
NT00119n
51
Gear Knob 250
New       £ 107.09
520396 (1) Full qty
NT00120n
52
Gear Knob Lock Nut 250
New       £ 21.73
53203 (1) Full qty
NT10173n
53
LEVER
520698 (1) Full qty
54
SWITCH GEARS
520547 (1) Full qty
55
SEEGER RING
AA15E (1) Full qty
56
CUP
520566 (1) Full qty
57
Molla centrale
104317 (1) Full qty
58
STUD (VALID TO N. 13591)
520700 (2) Full qty
59
Gear Lever Tower Stud M6 x 48.5mm
New       £ 4.35
520701 (2) Full qty
GB10497n
60
WASHER
8R4 (4) Full qty
61
NUT
1D8UNI209 (8) Full qty
62
SEAT SPHERICAL
521754 (1) Full qty
63
Gearbox Centering Dowel 365 GTB/4 Daytona
New       £ 59.90
8GC1 (2) Full qty
GB10403n
64
COVER
520543 (1) Full qty
65
Carb Mounting Washer M8
8R5 (4) Full qty
65
Carburettor Base Nut M8x1 [11m…
8R5 (4) Full qty
65
Carb Mounting Washer M8
8R5 (4) Full qty
66
SEEGER RING
AA5E (2) Full qty
67
Gear Linkage Pin
New       £ 4.35
521542 (1) Full qty
AX22541n
68
Transaxle Filler Plug
New       £ 41.75
104282 (1) Full qty
AX22311n
69
GASKET
520161 (1) Full qty
70
Engine Mounting 330 (86mm)
131251 (1) Full qty
70
Gearbox Mount
131251 (1) Full qty
71
WASHER
10R1 (1) Full qty
72
WASHER
10R4 (1) Full qty
73
NUT
95009 (1) Full qty
