Gearbox Assembly


Schematic: Gearbox Assembly
Schematic: Gearbox Assembly
Loc
Part
Cond       Price
1
Gear Knob 250/Lusso Long
New       £ 237.02
520396 (1) Full qty
NT00119n
1
Gear Knob 250
New       £ 107.09
520396 (1) Full qty
NT00120n
1
Gear Knob 250/Lusso Short
New       £ 237.02
520396 (1) Full qty
NT35367n
2
Gearstick (Chrome) 250/330
55497 (1) Full qty
2
Gear Lever 250 SWB
New       £ 357.50
55497 (1) Full qty
GB10509n
2
Gear Lever 250 SWB
Used       Price on Enquiry
55497 (1) Full qty
GB10509u
3
Gear Lever Gaiter 250
New       £ 64.11
NT10069n (1) Full qty
NT10069n
4
Gear Lever Gaitor O-Ring
New       Price on Enquiry
GB11729n (1) Full qty
GB11729n
5
M6 Stud x 23.0 Long 250
New       Price on Enquiry
GB00299n (23) Full qty
GB00299n
6
M6 Wavy Washer 250
New       Price on Enquiry
GB00233n (17) Full qty
GB00233n
7
Nut M6 250
New       Price on Enquiry
GB00304n (25) Full qty
GB00304n
8
Gear Lever Cup
New       £ 78.65
55456 (2) Full qty
GB10345n
9
Gear lever yoke spacer 250
New       Price on Enquiry
53128 (2) Full qty
GB00297n
10
Selector Turret 250
New       Price on Enquiry
53043 (1) Full qty
GB00292n
11
Gear lever pivot bolt 250
New       Price on Enquiry
53130 (1) Full qty
GB00295n
11
Gear lever spring retention bolt 250
New       Price on Enquiry
53130 (1) Full qty
GB00302n
12
Gearbox Turret Shim/Spacer
93300 (2) Full qty
13
Gear lever yoke 250
New       Price on Enquiry
53129 (1) Full qty
GB00294n
14
Gear Lever Turret Gasket 250,330
New       £ 3.94
55471 (1) Full qty
GB00034n
14
Trans Gasket
New       Price on Enquiry
55471 (1) Full qty
GB10264n
15
M8 lockwire bolt 250
New       Price on Enquiry
93231 (3) Full qty
GB00250n
15
Selector Bolt
New       £ 16.45
93231 (3) Full qty
GB10544n
16
Lock Washer M6
New       £ 1.55
92387 (2) Full qty
GB11721n
17
1st / 2nd selector tang 250
GB00263n (1) Full qty
18
Split pin Dia 5/64x1 1/2 LG 250
New       Price on Enquiry
GB00279n (2) Full qty
GB00279n
19
Gear lever pivot castellated nut 250
New       Price on Enquiry
92504 (1) Full qty
GB00296n
20
Speedo Angle Drive 250
New       £ 1275.00
101353 (1) Full qty
GB00076n
20
Speedo Angle Drive 250
Used       £ 664.40
101353 (1) Full qty
GB00076u
20
Speedo Angle Drive 275/330/365
New       £ 474.03
101353 (1) Full qty
GB00091n
20
Speedo Angle Drive 246/275/330/365/400
New       Price on Enquiry
101353 (1) Full qty
GB10262n
21
M6 stud x 20.0 Long 250
New       Price on Enquiry
GB00209n (9) Full qty
GB00209n
22
Dowel Dia 10x15 LG 250
93342 (2) Full qty
22
Dowel Dia 10x15 LG 250
New       Price on Enquiry
93342 (2) Full qty
GB00280n
23
M8 Stud x 33.0 Long 250
New       Price on Enquiry
GB00301n (2) Full qty
GB00301n
24
Tail cap 250
New       Price on Enquiry
53049 (1) Full qty
GB00293n
25
Gearbox Tail Case Early 250
53191 (1) Full qty
26
M8 x 1.0 nut 250
New       Price on Enquiry
GB00223n (33) Full qty
GB00223n
27
Do Not Use - See GE07667n
12601374 (33) Full qty
27
Rocker Block Wavy Washer
New       £ 0.12
12601374 (33) Full qty
CH11905n
27
M8 Wavy Washer
New       £ 1.08
12601374 (33) Full qty
GE07667n
28
Reverse plunger cap 250
New       Price on Enquiry
53122 (1) Full qty
GB00269n
29
Spring
New       £ 12.95
53121 (1) Full qty
GB11723n
30
Reverse detent plunger 250
New       Price on Enquiry
GB00268n (1) Full qty
GB00268n
31
Selector Rail, Reverse 250
New       Price on Enquiry
53108 (1) Full qty
GB00262n
32
Reverse selector tang with detent 250
New       Price on Enquiry
GB00264n (1) Full qty
GB00264n
33
Selector Rail, 3rd-4th 250
New       Price on Enquiry
53530 (1) Full qty
GB00261n
34
Selector Rail, 1st-2nd 250
New       Price on Enquiry
53529 (1) Full qty
GB00259n
35
Selector interlock bullet - Short 250
New       Price on Enquiry
53126/100748 (1) Full qty
GB00275n
36
M7 x 10 Hex Head bolt 250
New       Price on Enquiry
GB00289n (1) Full qty
GB00289n
37
M7 Wavy Washer
New       Price on Enquiry
GE35711n (1) Full qty
GE35711n
38
Dowel Dia 12x25 LG 250
New       Price on Enquiry
93343 (2) Full qty
GB00282n
39
M5 stud x 22.0 Long 250
New       Price on Enquiry
GB00208n (12) Full qty
GB00208n
40
Reverse idler spindle bolt 250
New       Price on Enquiry
93295 (1) Full qty
GB00270n
41
M8 Locking Tab washer 250
New       Price on Enquiry
GB00290n (1) Full qty
GB00290n
42
Castellated Nut M8x1.0 250
92638 (1) Full qty
42
Castellated Nut M8x1.0 250
92638 (1) Full qty
43
M8 Plain Washer Black
New       £ 1.08
GE07666n (1) Full qty
GE07666n
44
Bush
New       Price on Enquiry
93333 (1) Full qty
GB11725n
45
Gearbox Mounting Bush 250
53135 (2) Full qty
45
Rubber Mount
New       Price on Enquiry
53135 (2) Full qty
GB10310n
46
Gearbox Mounting Cup 250,275
100735 (2) Full qty
46
Do Not Use - See GB10072n
100735 (2) Full qty
47
Gearbox Centre Mount Bolt
94777 (1) Full qty
47
Gearbox Centre Mount Bolt
94777 (1) Full qty
48
Centrecase 250
53045 (1) Full qty
48
Gearbox Casing 250 Front Pump
53045 (1) Full qty
49
Pivot Arm, Reverse 250
New       Price on Enquiry
53112 (1) Full qty
GB00267n
50
Selector Fork, Reverse 250
53111 (1) Full qty
50
Selector Fork, Reverse 250
New       Price on Enquiry
53111 (1) Full qty
GB00258n
51
Actuator, Reverse 250
New       Price on Enquiry
53114 (1) Full qty
GB00266n
52
Pivot Shaft, Reverse 250
53113 (1) Full qty
52
Pivot Shaft, Reverse 250
New       Price on Enquiry
53113 (1) Full qty
GB00271n
53
Bearing retaining plate - main…
53093 (1) Full qty
53
Bearing retaining plate - maincase 250
New       Price on Enquiry
53093 (1) Full qty
GB00225n
54
M6 Countersunk Screw
New       £ 4.35
93834 (1) Full qty
GB10379n
55
Time Sert M6x1x12mm
New       £ 4.29
GE07677n (7) Full qty
GE07677n
56
M8 stud x 44.0 Long 250
New       Price on Enquiry
GB00211n (1) Full qty
GB00211n
57
Gearbox Drain Plug M16x1.5
GB10133n (1) Full qty
58
Drain Bung Copper washer for M16x1.5 250
New       Price on Enquiry
93332 (1) Full qty
GB00227n
59
Gearbox Main Casing Oil Plug M…
53115 (1) Full qty
60
Filler lever copper washer for…
53116 (1) Full qty
61
Gearbox Case Aluminium 250 GTO/SWB
New       £ 3932.50
55090 (1) Full qty
GB00135n
62
Oil strainer gasket - Ferrari 250 GTO 250
New       Price on Enquiry
52943 (1) Full qty
GB00234n
63
Gearbox Filter 250 Front Pump
53151 (1) Full qty
64
M8 stud x 57.0 Long 250
New       Price on Enquiry
GB00213n (1) Full qty
GB00213n
65
M8 stud x 50.0 Long 250
New       Price on Enquiry
GB00212n (1) Full qty
GB00212n
66
M5 Nut Black
New       Price on Enquiry
GE35645n (4) Full qty
GE35645n
67
M5 Wavy Washer Black
New       Price on Enquiry
GE35649n (4) Full qty
GE35649n
68
M8 Stud x 44.0 Long 250
New       Price on Enquiry
GB00277n (4) Full qty
GB00277n
69
Oil pump gear - driver 250
New       Price on Enquiry
52451 (1) Full qty
GB00201n
70
Bush-oil pump gear 250
New       Price on Enquiry
53453 (2) Full qty
GB00203n
71
Oil pump gear - driven 250
New       Price on Enquiry
52452 (1) Full qty
GB00202n
71
Oil Pump Gear 250 Europa/GT 330, 365
New       £ 142.45
52452 (1) Full qty
GB10385n
72
Side Cover, Pump Gears 250
New       Price on Enquiry
52937 (1) Full qty
GB00204n
73
M8 stud x 37.0 Long 250
New       Price on Enquiry
GB00210n (5) Full qty
GB00210n
74
Dia 11.0 hollow dowel - Bell housing 250
New       Price on Enquiry
93341 (1) Full qty
GB00206n
75
M8 x 1.0 Pitch x 25.0 Long 250
New       Price on Enquiry
GB00291n (2) Full qty
GB00291n
76
Selector Fork 3rd/4th 250,330 GT
New       £ 724.79
53528 (1) Full qty
GB00186n
77
Gearbox Top Gasket 250,330
53047 (1) Full qty
77
Gearbox Gasket 330 GT MkII
53047 (1) Full qty
78
Top cover 250
New       Price on Enquiry
53046 (1) Full qty
GB00224n
79
Selector Fork 1st/2nd 250,330 GT
New       £ 724.79
53527 (1) Full qty
GB00187n
80
Selector detent spring bush 250
New       Price on Enquiry
100749 (1) Full qty
GB00228n
80
Selector Spring Bush
New       Price on Enquiry
100749 (1) Full qty
GB10493n
81
Gearbox Detent Spring
55786 (1) Full qty
81
Relief Spring 5 Speed Conversion
New       Price on Enquiry
55786 (1) Full qty
GB10549n
82
Detent Spring Ball
New       Price on Enquiry
101612 (1) Full qty
GB10491n
