Tyre Pressure Monitoring System


Schematic: Tyre Pressure Monitoring System
Loc
Part
Cond       Price
1
ELECTRIC PUMP
328447 (1) Full qty
2
REAR CRASH BRACKET ON BACK PAN…
275321 (1) Full qty
3
New       £ 2.19
256490 (3) Full qty
BW99303n
4
PUMP MOUNTING BRACKET
314656 (1) Full qty
5
PLUG -40 x 24 mm-
264740 (2) Full qty
6
INSULATION
285319 (1) Full qty
7
SCREW
304224 (2) Full qty
8
SHIM
255048 (2) Full qty
9
GROMMET
255047 (2) Full qty
10
FLOW SEPARATOR
260390 (1) Full qty
11
SCREW -M8 X 25-
210246 (2) Full qty
12
WASHER
13578305 (2) Full qty
13
PIPE FROM PUMP TO FLOW SEPARAT…
328418 (1) Full qty
14
PIPE FROM SEPARATOR TO THREE W…
268839 (1) Full qty
15
DISTRIBUTOR BLOCK
269858 (1) Full qty
16
CYLINDRICAL BUSHING
258770 (1) Full qty
17
NUT
14039614 (1) Full qty
18
PIPE FROM THREE WAY UNION TO R…
268840 (1) Full qty
19
PIPE FROM THREE WAY UNION TO R…
268842 (1) Full qty
20
PIPE FROM SECTION TO LH REAR W…
271154 (1) Full qty
21
REAR SECTION PIPE
274976 (1) Full qty
22
PIPE FROM FRONT UNDERBODY SECT…
268846 (1) Full qty
23
DISTRIBUTOR BLOCK
269858 (1) Full qty
24
CYLINDRICAL BUSHING
258770 (1) Full qty
25
NUT
14039614 (1) Full qty
26
PIPE FROM THREE WAY UNION TO F…
271160 (1) Full qty
27
PIPE FROM RH FRONT SECTION TO …
271161 (1) Full qty
28
PIPE FROM THREE WAY UNION TO F…
271158 (1) Full qty
29
PIPE FROM LH FRONT SECTION TO …
271159 (1) Full qty
30
HEAT SHIELD
83676100 (1) Full qty
31
CLIP
234285 (4) Full qty
32
PIPE FROM SECTION TO RH REAR W…
271155 (1) Full qty
33
CLIP -1 compartment-
234284 (5) Full qty
34
Front Brake Calipar - Clamp
116374 (4) Full qty
35
FRONT LH BRACKET
271901 (1) Full qty
36
FRONT RH BRACKET
271902 (1) Full qty
37
REAR LH BRACKET
330723 (1) Full qty
38
REAR RH BRACKET
330724 (1) Full qty
39
COMPL. LIFT SYSTEM INSPECTION …
272640 (1) Full qty
40
SCREW -M5 X 12-
85692200 (3) Full qty
41
FLOOR SECTION PIPE
274974 (1) Full qty
42
RUBBER RETAINER
262737 (1) Full qty
43
FLOW SEPARATOR FASTENER PLATE
314713 (1) Full qty
44
SCREW
301785 (2) Full qty
