Internal Elements Body -Lower And Central Zone -


Schematic: Internal Elements Body -Lower And Central Zone -
Schematic: Internal Elements Body -Lower And Central Zone -
Loc
Part
Cond       Price
1
R.H. frame work covering
62476400 (1) Full qty
1
R.H. frame work covering
62758000 (1) Full qty
2
R.H. and L.H. covering
62503400 (2) Full qty
2
L.H. frame work covering
62476500 (1) Full qty
2
L.H. frame work covering
62758100 (1) Full qty
3
R.H. frame work covering
62476800 (1) Full qty
4
L.H. frame work covering
62476900 (1) Full qty
4
R.H. and L.H. covering
62504100 (2) Full qty
5
Window plane covering
62476200 (1) Full qty
5
Covering
62503300 (1) Full qty
6
Covering
62503700 (1) Full qty
6
Front frame work covering
62479600 (1) Full qty
7
R.H. front frame work covering…
62479900 (1) Full qty
7
R.H. front frame work covering…
62748100 (1) Full qty
8
L.H. front frame work covering…
62748400 (1) Full qty
8
R.H. and L.H. covering
62503800 (2) Full qty
8
L.H. front frame work covering…
62480000 (1) Full qty
8
R.H. and L.H. covering
62748200 (1) Full qty
9
Frame work
62419100 (1) Full qty
10
Rivet
61755900 (45) Full qty
11
Central insulation
62488900 (1) Full qty
12
R.H. insulation
62489000 (1) Full qty
13
L.H. insulation
62489100 (1) Full qty
14
Covering
62539200 (1) Full qty
14
Central shield interior - en…
62573600 (1) Full qty
15
R.H. shield (without covering)…
62418900 (1) Full qty
15
Covering
62539900 (1) Full qty
16
Covering
62540000 (1) Full qty
16
L.H. shield (without covering)…
62419000 (1) Full qty
17
R.H. lower frame work covering…
62552900 (1) Full qty
17
Covering
62539700 (1) Full qty
18
Covering
62539800 (1) Full qty
18
L.H. lower frame work covering…
62553000 (1) Full qty
19
Screw
15908506 (6) Full qty
20
Washer
12611607 (6) Full qty
21
Rivet
62498300 (22) Full qty
22
Pin l.15
61767700 (0) Full qty
22
Pin l. 24
62547100 (0) Full qty
22
Pin l. 20
62547000 (0) Full qty
23
Clip
61411200 (10) Full qty
24
R.H. complete control unit cov…
62553200 (1) Full qty
24
Covering
62539500 (1) Full qty
25
Covering
62539600 (1) Full qty
25
L.H. complete control unit cov…
62553300 (1) Full qty
26
Button
60727200 (2) Full qty
27
Male connector for button
60084407 (2) Full qty
28
R.H. side panel
62419400 (1) Full qty
28
L.H. side panel
62419500 (1) Full qty
29
Rivet
62498300 (24) Full qty
30
Bushing
62569300 (4) Full qty
31
R.H. lower frame work covering…
62747300 (1) Full qty
31
Covering
62747500 (1) Full qty
32
L.H. lower frame work covering…
62747400 (1) Full qty
32
Covering
62747600 (1) Full qty
33
R.H. complete control unit cov…
62746900 (1) Full qty
33
Covering
62747100 (1) Full qty
34
L.H. complete control unit cov…
62747000 (1) Full qty
34
Covering
62747200 (1) Full qty
35
Bushing
62471400 (10) Full qty
