Output Shaft Assembly


Schematic: Output Shaft Assembly
Schematic: Output Shaft Assembly
Loc
Part
Cond       Price
1
Output Flange 250
New       Price on Enquiry
56896 (1) Full qty
GB00252n
2
Input/Output Shaft Seal 250 (30x52x10)R23
New       £ 26.19
95850205 (1) Full qty
GB10018n
2
Oil Seal 30/52/10
New       Price on Enquiry
95850205 (1) Full qty
GE00500n
3
40mm External Circlip
New       Price on Enquiry
GE00707n (1) Full qty
GE00707n
4
Rear Tailshaft Bearing 250
New       £ 134.13
GB10024n (1) Full qty
GB10024n
5
Output Bush 250
New       Price on Enquiry
GB00249n (1) Full qty
GB00249n
6
Spacer output shaft 250
New       Price on Enquiry
56897 (1) Full qty
GB00246n
7
M4 x 6mm Button Head Bolt
New       Price on Enquiry
GB10550n (1) Full qty
GB10550n
8
Speedo Drive Gears 250 ( Pair )
New       £ 131.84
GB00182n (1) Full qty
GB00182n
9
Output Shaft 250
New       Price on Enquiry
53192 (1) Full qty
GB00248n
10
M8 lockwire bolt 250
New       Price on Enquiry
93231 (4) Full qty
GB00250n
10
Selector Bolt
New       £ 16.45
93231 (4) Full qty
GB10544n
11
Mainshaft oil plug M12x1.0 250
New       Price on Enquiry
GB00243n (1) Full qty
GB00243n
12
Mainshaft Rear Nut
New       £ 65.16
93326 (1) Full qty
GB10047n
13
Mainshaft Lock Washer (Rear)
New       £ 12.93
93748 (1) Full qty
GB10054n
14
Shim Bearing to 1st 250
New       £ 103.16
53557 (1) Full qty
GB10038n
15
Sealing Ring Output Shaft 250 GT 330 GT
New       £ 6.04
55188 (2) Full qty
GB10215n
16
12mm dowel - Output shaft to r…
55100 (2) Full qty
16
Gearbox Dowel
55100 (2) Full qty
17
Gear, Reverse Output 250
New       Price on Enquiry
53750 (1) Full qty
GB00241n
18
Spacer input shaft 250
New       Price on Enquiry
53536 (1) Full qty
GB00244n
19
M6 Countersunk Screw
New       £ 4.35
93834 (7) Full qty
GB10379n
20
Bearing retaining plate - main…
53093 (1) Full qty
20
Bearing retaining plate - maincase 250
New       Price on Enquiry
53093 (1) Full qty
GB00225n
21
Front/Rear Main Shaft Bearing …
95890501 (1) Full qty
22
Spacer - Large internal and external chamfer 250
New       Price on Enquiry
GB00245n (1) Full qty
GB00245n
23
Primary Shaft 250
New       Price on Enquiry
53726 (1) Full qty
GB00236n
23
Output Shaft 250 GTE (100mm)
Used       £ 1402.50
53726 (1) Full qty
GB10585u
24
Sleeve for 1st Gear 250 (Upgrade)
New       Price on Enquiry
54924/A (1) Full qty
GB10604n
24
Caged Needle Roller 1st Gear 250
New       Price on Enquiry
54924/A (1) Full qty
GB10606n
25
Sleeve for 1st Gear 250 (Upgrade)
New       Price on Enquiry
54924/A (2) Full qty
GB10604n
25
Caged Needle Roller 1st Gear 250
New       Price on Enquiry
54924/A (2) Full qty
GB10606n
26
Output Gear, 1st 250
New       Price on Enquiry
53747 (1) Full qty
GB00237n
27
Mainshaft Front Nut 250
New       £ 106.07
53517 (1) Full qty
GB10046n
27
Mainshaft Front Nut 250
Used       Price on Enquiry
53517 (1) Full qty
GB10046u
28
Mainshaft Spigot Bearing 250
New       £ 27.23
95893006 (1) Full qty
GB10030n
29
M/S oil feed connector 250
New       Price on Enquiry
GB00242n (1) Full qty
GB00242n
30
Shim 1st to Spider 250
New       £ 102.85
54926 (1) Full qty
GB10036n
31
Synchro Dog Ring
53513 (1) Full qty
31
Synchro Dog Ring
New       £ 535.43
53513 (1) Full qty
GB10016n
32
Backing Ring
New       £ 396.28
53515 (3) Full qty
GB10078n
33
Synchro Ring 1st 4th 5th 250
New       £ 261.97
521767 (3) Full qty
GB00190n
34
Synchro Hub Circlip
New       Price on Enquiry
100722 (4) Full qty
GB00042n
35
Manicotto Sliding Hub 250/275
New       £ 599.56
522047 (2) Full qty
GB10014n
35
Manicotto Sliding Hub 250/275
Used       £ 548.90
522047 (2) Full qty
GB10014u
36
Synchro Spiders [1st/2nd] 250
New       £ 598.95
53509 (1) Full qty
GB00188n
37
Shim 2nd to 3rd / 3rd to Spider 250
New       £ 103.55
54929 (3) Full qty
GB10042n
38
Output Gear, 2nd 250
New       Price on Enquiry
53748 (1) Full qty
GB00238n
39
Sleeve for 2nd/3rd 250 (Upgrade)
New       Price on Enquiry
54927/A (4) Full qty
GB10605n
39
Caged Needle Roller 2nd/3rd Gear 250
New       Price on Enquiry
54927/A (4) Full qty
GB10607n
40
Sleeve for 2nd/3rd 250 (Upgrade)
New       Price on Enquiry
54927/A (2) Full qty
GB10605n
40
Caged Needle Roller 2nd/3rd Gear 250
New       Price on Enquiry
54927/A (2) Full qty
GB10607n
41
Output Gear, 3rd 250
New       Price on Enquiry
53749 (1) Full qty
GB00239n
42
Synchro Spider 3rd/4th 250
New       £ 598.95
53510 (1) Full qty
GB00189n
43
Seal Backing Plate (Ricardo 4 Spd Gearbox)
New       Price on Enquiry
GB11717n (1) Full qty
GB11717n
44
Seal 10/22/7
New       £ 6.00
92968 (1) Full qty
GB10311n
45
Input Shaft 250/330
New       £ 1839.20
52083 (1) Full qty
GB10121n
46
Primary Shaft Lock Washer
New       £ 16.12
93747 (1) Full qty
GB10048n
47
Front Input Shaft Nut
New       £ 69.65
93330 (1) Full qty
GB10058n
48
Bell Housing O Ring (64x3.5)
New       £ 1.52
95860024 (2) Full qty
GB10069n
48
O-Ring OR167
New       Price on Enquiry
95860024 (2) Full qty
GE00402n
